Working chamber dimensions Width mm 1000 Height mm 1500 Depth mm 1000 Max. external dimensions Width mm 1840 Height mm 2389 I 2443 Depth mm 1450 Volume Working chamber volume m3 1.5 Vapour chamber volume m3 2.447 Shelves (max. no.) 15 Weights Weight of empty oven kg 780 I 800 Load capacity kg 400 Load (reinforced inner casing) kg 1000 Floor load kg 200 Reinforced floor load kg 1000 Charging trolley (max.) kg 300 Shelves, concentrated load kg 10 Shelves, area load kg 20 Grate, concentrated load kg 50 Grate, area load kg 200 Electrical power Heat output, standard kW 27.0 Connected load, standard kW 29.0 Heat output, reduced kW 18.0 Heat output, increased kW 36.0 Rated voltage V 400 Power consumption air circulation 250 °C kWh/h 6.8 Power consumption exhaust air at 250 °C kWh/h 11.2 Degree of protection IP 54 Temperature Nominal temperature 250 °C K Nominal temperature 300 °C K Nominal temperature 350 °C K Temperature distribution, spatial at 250 °C (circulating air) K ±2.6 at 300 °C (circulating air) K ±3.1 at 350 °C (circulating air) K ±3.5 at 250 °C (fresh air)* K ±3.0 at 300 °C (fresh air)* K ±3.6 Time Rise Time, circulating air to 250 °C min. 30 to 300 °C min. 35 Cooling rate to 60 °C* from 250 °C min. 48 from 300 °C min. 61 Recovery time to 250 °C after 30 sec. min. 2.5 after 60 sec. min. 3 Quantity of solvent max. at 250 °C g 46 at 300 °C g 37 Air flow (horizontal) Air velocity m/s 0.6 Circulating air (fan output) m3/h 3400 Exhaust air for VTU I VTL m3/h 60 I 360 Air changes for VTU I VTL min-1 0.4 I 2.5 Noise level dB (A) < 70 with air outlet blower
