Cheap orientation test instrument

1085

Cheap orientation test instrument
Specification:
Power supply:      9V
Test Voltage:        9V
Temperature range:
Operating:            (5°-49°C)
Relative humidity (0-90%]
Resolution:           One oder of magnitude
Accuracy:               ±5%
Repeatability        ±5%
Weight:                  170g
Size:                        130x72x30(mm)

The Led that iluminates constantly is the dacade mesured:
103 1 kilohm Green LED 109 1,000 mega ohms Yellow LED
104 10 kilohms Green LED 1010 10,000 mega ohms Yellow LED
105 100 kiloms Green LED 1011 100,000 mega ohms Yellow LED
106 1 mega ohm Yellow LED 1012 1,000,000 mega ohms Red LED
107 10 mega ohms Yellow LED >1012 insulate Red LED
108 100 mega ohms Yellow LED
